• Oversized roller bearings
• Fully anodized crankcase
• Innovative new seal design extends seal life
• New plunger design improves thermal
shock resistance
• New valve plate covers
FEATURES

SPECIFICATIONS

Pump Model TSF3121
Maximum Volume 18.5 GPM
Maximum Discharge Pressure 2175 PSI
Horsepower 27.5 EBHP
Maximum Pump Speed 1450 RPM
Inlet Pressure Flooded to 70 PSI
Plunger Bore (in / mm) 1.220 in. / 31 mm
Plunger Stroke (in / mm) .826 in. / 21 mm
Oil Capacity 33.8 oz.
Maximum Fluid Temp 165° F
Inlet Port Thread 1" BSPP-F
Discharge Port Thread 1/2 BSPP-F
Shaft Diameter (in / mm) .945 in. / 24 mm
Weight 49.2 lbs / 22.3 kg
Dimensions 13.60" x 9.55" x 7.48"
